Goobay
CAT 6A Network Cable, U/UTP, blue
Copper conductor (CU), AWG 23/1 (solid), halogen-free cable sheath (LSZH)
/5
Product and packaging similar. Subject to modifications and errors.
Goobay
CAT 6A Network Cable, U/UTP, blue
Copper conductor (CU), AWG 23/1 (solid), halogen-free cable sheath (LSZH)
Article details
Our patch cables transmit signals in top quality at high speed, always guaranteeing a stable connection. High-quality inner conductors, robust cable sheathing and precisely fitting plugs distinguish our portfolio of connection cables. Goobay always provides the perfect products for your network needs - whether you aim to set up a home or company network. Simply. All. You need!
  • Unshielded twisted-pair LAN cable for the small office and working from home (SOHO and WFH applications)
  • Unterminated patch cable for assembly and installation with IDC connection technology
  • Flexible data and installation cable for indoor assembly with a maximum transmission length of 40 m
  • High-quality copper conductor (CU) guarantees an excellent and powerful network connection.
  • In the event of a fire, the halogen-free jacket of the Ethernet cable prevents the outgassing of hazardous substances and minimises smoke development
  • Complies with the Construction Products Regulation (CPR) and Eca fire protection class
  • Complies with the Construction Products Regulation (CPR) and Eca fire protection class
Technical specifications
Cable
Diameter of insulated conductor
1.03 mm (+/-0.05)
AWG
23/1 (solid)
Specification
CAT 6A
Cable sheath diameter (approx.)
6 mm
Shielding class
U/UTP
Cable type
round cable
Material cable sheath
LSZH
Inner conductor material
CU (copper)
LSZH compliant
yes
Fire class (CPR)
Eca
Cable length
50 m
Signal transmission
usable up to cable length
90 m
Impedance
100 Ω
max. bandwidth
500 MHz
General
Markings
ECA_CPR, CE
Color
blue
Packaging type
Cable ring-coil
Dimensions / Weight
Consumption Unit
1 pc. coil
Downloads
Product data sheet pdf Declaration of conformity pdf Declaration of conformity pdf
Packing units:
1 / 4
Item: 96092
EAN: 4040849960925
