Toolless Cable Connector CAT 6A, STP Shielded
for IDC connection (toolless)
Toolless Cable Connector CAT 6A, STP Shielded
for IDC connection (toolless)
Article details
The cable connector is designed for 8-wire connection, extension, repair or rerouting of data cables. The major advantage of the connector over CAT connection boxes is its slim design. With the product, you can realise cable extensions even in confined space, e.g. in cable ducts. Goobay always provides the perfect products for your needs. Simply. All. You need!
- Shielded cable connection (STP) for extending or linking 2x LAN installation cables
- Connector module to reconnect damaged cables without re-routing an entire cable segment.
- For tool-free assembly by solderless, screwless and stripping-free connection technology IDC mounting)
- Max. data transmission of 500 MHz guarantees an excellent network connection.
- Suitable for unterminated patch cables with AWG 24/1 to 22/1 (conductor diameter: solid wire 0.5 - 0.64 mm, stranded wire 0.61 - 0.76 mm and cable sheath diameter: 5.0 - 9.7 mm)
- Very slim connection module with shield connection and integrated strain relief
- Field assembly cable connector made of high-quality zinc die-cast housing
Technical specifications
Connections
Connection, type
for IDC connection (toolless)
Connection 2, type
for IDC connection (toolless)
Cable
Specification
CAT 6A
Shielding class
STP
Signal transmission
max. bandwidth
500 MHz
General
Material
zinc die-cast
Packaging type
Bulk
Dimensions / Weight
Length
65 mm
Width
11 mm
Height
11 mm
Language Scope
Operation manual
de, en
Downloads
Packing units:
1 / 50 / 500
Item: 79579
EAN: 4040849795794
