LED Magnifying Lamp with Clamp, 10 W, black
800 lm, brightness & light colour adjustable, 127 mm glass lens, 1.75x magnification, 3 dioptres
LED Magnifying Lamp with Clamp, 10 W, black
800 lm, brightness & light colour adjustable, 127 mm glass lens, 1.75x magnification, 3 dioptres
Article details
- Brightness and light colour of the magnifier lamp are adjustable in 6 steps via separate touch panels, max. 800 lm, warm white to daylight-balanced (3500 - 6500 K).
- Lens head of the magnifying glass lamp can be tilted by up to 100° and swivelled by 250°, 127 mm lens diameter creates a harmonious LED ring illumination.
- Thanks to the quick-release, you can easily and toolfree replace the crystal glass lens of the magnifier with light with 3 dioptres and 1.75x magnification (incl. protective cap)
- Articulated arm of the magnifier lamp with integrated cable guide provides flexible 700 mm working radius.
- The multi-purpose craft magnifier is useful e.g. in the beauty sector, as a reading aid or for precision work such as embroidery and soldering.
- Ideally suitable as a table magnifying glass, a craft light, a desk, drawing or reading lamp
- The clip-on of the magnifying desk lamp is suitable for a table top thickness of up to 50 mm. Replacement table clamp: 64987, matching wall bracket: 64991.
Technical specifications
Battery
rechargeable
no
Connections
Connection, type
Europlug (Type C CEE 7/16)
Performance
Power consumption
10 W
luminous source
light emitting diode (LED)
Luminous color
variable/adjustable (warm white/classic white/cool white)
Illuminate-Type
SMD LED
Colour temperature from
3500 K
Dimmability
dimmable
Colour temperature to
6500 K
Luminous flux
800 lm
Rated luminous flux
800 lm
Useful luminous flux (Φuse)
Useful luminous flux (Φuse) in a wide cone (120°)
Non-directional or directional light source
DLS
color rendering index
80 Ra
Lamp service life factor
0.9
weighted energy consumption
10 kWh/1.000 h
operating voltage
20 V (DC)
Number of LEDs
60
Device connections
Output, min. amperage
0.5 A
Output, min. amperage
0.5 A
Cable
Cable length
1.5 m
Build
Beam Angle
108 °
cover type
lens
General
protection class
IP20
Appliance Class
III
Energy efficiency rating
F
Manufacturer designation
Goobay
Color
black
rated lamp lifetime
25000 hrs.
Material
plastic, metal, glass
Markings
WEEE, CE
Number of switching cycles
12500 pcs.
Applications
workshop
Peak luminous intensity (cd)
273
Chromaticity coordinate x
0.313
Chromaticity coordinate y
0.337
R9 colour rendering index value
1
lumen maintenance factor
0.96
Colour consistency in McAdam ellipses
1.8
Flicker metric (Pst LM)
0.1
Stroboscopic effect metric (SVM)
0.6
Packaging type
Retail Box
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
Width
650 mm
Height
820 mm
depth
205 mm
Weight
2232 g
accessory - Power supply
Output current
0.5 A
Input AC frequency
50/60 Hz
Input voltage
220-240 V
Model identifier
XY12LF-200050VH-EW
Input current
0.3 A
Output voltage
20.0 V
Output power
10.0 W
Language Scope
packaging
cs, da, de, en, es, fr, it, nl, pl, sv
Downloads
Packing units:
1 / 4
Item: 64986
EAN: 4040849649868
