Goobay
LED Magnifying Lamp with Clamp, 10 W, black
800 lm, brightness & light colour adjustable, 127 mm glass lens, 1.75x magnification, 3 dioptres
Goobay
LED Magnifying Lamp with Clamp, 10 W, black
800 lm, brightness & light colour adjustable, 127 mm glass lens, 1.75x magnification, 3 dioptres
Article details
  • Brightness and light colour of the magnifier lamp are adjustable in 6 steps via separate touch panels, max. 800 lm, warm white to daylight-balanced (3500 - 6500 K).
  • Lens head of the magnifying glass lamp can be tilted by up to 100° and swivelled by 250°, 127 mm lens diameter creates a harmonious LED ring illumination.
  • Thanks to the quick-release, you can easily and toolfree replace the crystal glass lens of the magnifier with light with 3 dioptres and 1.75x magnification (incl. protective cap)
  • Articulated arm of the magnifier lamp with integrated cable guide provides flexible 700 mm working radius.
  • The multi-purpose craft magnifier is useful e.g. in the beauty sector, as a reading aid or for precision work such as embroidery and soldering.
  • Ideally suitable as a table magnifying glass, a craft light, a desk, drawing or reading lamp
  • The clip-on of the magnifying desk lamp is suitable for a table top thickness of up to 50 mm. Replacement table clamp: 64987, matching wall bracket: 64991.
Technical specifications
Battery
rechargeable
no
Connections
Connection, type
Europlug (Type C CEE 7/16)
Performance
luminous source
light emitting diode (LED)
Illuminate-Type
SMD LED
Power consumption
10 W
Colour temperature from
3500 K
Colour temperature to
6500 K
operating voltage
20 V (DC)
Luminous flux
800 lm
weighted energy consumption
10 kWh/1.000 h
Rated luminous flux
800 lm
Luminous color
variable/adjustable (warm white/classic white/cool white)
Useful luminous flux (Φuse)
Useful luminous flux (Φuse) in a wide cone (120°)
Non-directional or directional light source
DLS
Number of LEDs
60
Dimmability
dimmable
color rendering index
80 Ra
Lamp service life factor
0.9
Device connections
Output, min. amperage
0.5 A
Output, min. amperage
0.5 A
Cable
Cable length
1.5 m
Build
Beam Angle
108 °
cover type
lens
General
Number of switching cycles
12500 pcs.
Appliance Class
III
protection class
IP20
Stroboscopic effect metric (SVM)
0.6
Flicker metric (Pst LM)
0.1
Colour consistency in McAdam ellipses
1.8
lumen maintenance factor
0.96
Chromaticity coordinate y
0.337
Chromaticity coordinate x
0.313
Energy efficiency rating
F
Peak luminous intensity (cd)
273
R9 colour rendering index value
1
rated lamp lifetime
25000 hrs.
Color
black
Material
plastic, metal, glass
Markings
WEEE, CE
Applications
workshop
Packaging type
Retail Box
Dimensions / Weight
Consumption Unit
1 pc. in cardboard box
Width
650 mm
Height
820 mm
depth
205 mm
Weight
2232 g
accessory - Power supply
Output current
0.5 A
Input AC frequency
50/60 Hz
Input voltage
220-240 V
Model identifier
XY12LF-200050VH-EW
Input current
0.3 A
Output voltage
20.0 V
Output power
10.0 W
Language Scope
packaging
cs, da, de, en, es, fr, it, nl, pl, sv
Downloads
Packing units:
1 / 4
Item: 64986
EAN: 4040849649868
