Infrared Motion Detector
for flush ceiling mounting, 360° detection, 8 m range, for indoor use (IP20), suitable for LEDs
Infrared Motion Detector
for flush ceiling mounting, 360° detection, 8 m range, for indoor use (IP20), suitable for LEDs
Article details
The motion detector adapts perfectly to your lighting requirements: You can customise the sensitivity and switch-off delay with the slide control to make the connected light always switch on at the right time. For an increased sense of security and increased convenience.
- The 360° motion detector is ideal for automatic LED lighting systems or indoor security systems
- With four levels of sensitivity, the PIR sensor can be individually adjusted to the lighting conditions at the installation site using the slider
- Designed for quick and easy flush-mounted ceiling installation
- With a range of up to 8 m, the heat sensor precisely detects the movement of people and animals in the dark or in twilight
- Designed for quick and easy flush-mounted installation in ceilings at a height of 2.2 m to 4 m
- The switch-off delay after motion detection can be variably set between 10 s and 15 min
- Max. rated power of the infrared detector: 800 W for incandescent lamps, 400 W for energy-saving lamps
Technical specifications
Connections
Connection, type
Screw clamp
Performance
minimum load
1
Power consumption
800 W
sensor type
passive infrared (PIR)
operating voltage
230 V (AC)
max view angle
360 °
switch-off delay from
10 s
switch-off delay to
900 s
Installation height from
2.2 m
Installation Height up to
4 m
max. detection range
8 m
recommended installation height
2.2 - 4 m
Light sensitivity from
3 lx
light sensitivity up to
2000 lx
General
protection class
IP20
Color
white
Markings
CE, WEEE, Haus
Special feature
Sensor function
Packaging type
Retail Box
Dimensions / Weight
Length
61.4 mm
Width
80 mm
Weight
94 g
Consumption Unit
1 pc. in cardboard box
Language Scope
Operation manual
en, de, fr, it
packaging
en, de, fr, it
Downloads
Packing units:
1 / 24 / 48
Item: 71362
EAN: 4040849713620
